Automatic Microscale Vapor Pressure Analyzer

K24870 - Automatic Microscale Vapor Pressure Analyzer (Operational Video)

Smart Advanced Features

Confirms to the specifications of

• ASTM D6450 and D7094
• Excellent Correlation to: ASTM D56, D93, D3278, D3828; IP 170; EN ISO 6379 / 3680; ISO 2719; SH/T 0768, SH/T 3077.1, SH/T 3077.2, DL/T 1354, GB/T 261, GB/T 21615, GB/T 5208, GB/T 21790

Fully Automatic & Environment friendly

• Automatic determination of flash points
• Automatic corrections for ambient atmospheric
• Less sample demand, lower test cost and less pollution

Highest Performance & Safety Standards

• Continuously closed cup operation with high safety and no open flame
• Built-in refrigeration module with high efficiency

Industrial Touch Screen User Interface

• 7-inch Integrated Color Touch Screen
• Built-in standard test methods which can be correlated to other closed cup methods
• Real-time display of temperature and pressure curves

Expanded Software Capabilities

• Pre-programmed methods - each with its own interface
• User friendly, easily toggle between parameter view and graphic view
• When the expected flash point is entered, the initial and end temperatures are automatically calculated
• Results will automatically appear on the screen after completion of the test
• Built-in storage of up to 1,000 test results

LIMS & future ready Network Connections

• RS232 interface for connection to thermal printer
• USB interface for external connection devices
