MA-3 Solo

MA-3 Solo is designed to be as simple to use as possible. Unlike other systems that require purified oxygen gas, purified air is used as the combustion and carrier gas. This design concept makes the instrument perfect for field portable operation or for use in mobile laboratories. The ceramic sample boats are easily cleaned for reuse. No gas requirement and reusable boats keep operating costs low.

 MA-3 Solo’s modern software is intuitive to use and provides a real-time graphical representation of the measurement status.

MA-3 Solo
Request Info/Quote

Specifications

Applications

Sediment, Soil, Food, Biological tissue, Blood, Urine, Ore, Coal, Plastics, Crude oil, Waste water and more

Measuring Objects

Solid sample, liquid sample, gaseous sample

Regulatory Compliant Test Methods

USEPA 7473, ASTM D 6722-01, ASTM D 7623-10, UOP 1009-15, UOP-938-20, JIS K0102

MA-3 Solo

FEATURES

  • Affordable robust design with a wide measurement range:
    Engineered for affordability, with easy-to-use manual boat loading and a sturdy “quick twist” load lock. Simple to operate and delivers a wide measurement range of 0 to 10,000 ng with quick analysis time ranging from 5 to 12 minutes.
  • Direct measurements – no sample pre-treatment needed:
    Eliminate any possibility of contamination and error from handling and reagents during chemical preparation, yielding highly accurate and precise results.
  • Inexpensive operation – no gases or consumables required:
    Design concept makes the instrument perfect for field portable operation or for use in mobile laboratories. The ceramic sample boats are easily cleaned for reuse. No gas requirement need and reusable boats keep operating costs low.
  • Advanced optics for superior sensitivity and stability:
    Employing a high-quality thermally stabilized Hg-discharge lamp that emits a very strong, stable line emission at 253.7 nm eliminates the need for any intensity-robbing optical filtering of the source. Two rugged semi-conductor detectors provide the quantitative and reference measurements, ensuring a long lifetime of trouble-free operation.
  • Real-time continuous diagnostics:
    MA-3 Solo’s software continuously monitors key diagnostics, such as all heater temps, flow rates, valve actuations, and voltages. This allows the software to automatically prompt user if there is an issue, and it also allows for quick and easy troubleshooting for maximum uptime and reliability.
  • Compact and lightweight design for portability:
    Engineered for portability, the MA-3 Solo has built-in ergonomic handles and weighs just 13 kg (~28 lbs). It can run on any standard single-phase wall power, from 100 to 240 VAC (50/60 Hz). The rugged design is perfect for field operation or for use in mobile labs.
  • Windows-based and user-friendly graphical software:
    Running under the Microsoft Windows operating system, the MA-3 Solo’s modern software is intuitive to use and provides a real-time graphical representation of the measurement status.
